机场搭建: v2board分支版本安装,支持vless/Hysteria

原版的v2board面板是不支持vless和Hysteria的,这里的v2board是在原版基础上的修改版,此修改版可以在原版的基础上丝滑一键升级。

一、介绍

v2board分支版本及对应的配套后端项目地址:

二、安装v2board修改版

v2board修改版的安装步骤,跟原版安装过程一致,参考我前面写的原版安装教程: 机场搭建: 通过aaPanel安装v2board及完成后端对接

  • 新安装

如果是新安装的环境,执行:

git clone https://github.com/wyx2685/v2board.git

克隆完项目,执行安装脚本:

sh init.sh
  • 从原版升级

丝滑升级:

git remote set-url origin https://github.com/wyx2685/v2board
git checkout master
./update.sh

然后参考【机场搭建: 通过aaPanel安装v2board及完成后端对接】在aaPanel重启队列。

三、安装XrayR修改版

v2board对应的xrayR修改分支安装步骤如下:

wget -N https://raw.githubusercontent.com/wyx2685/XrayR-release/master/install.sh && bash install.sh

很快安装完毕,接下来修改配置文件(前提是你在v2board添加好节点),配置文件对应/etc/XrayR,执行命令XrayR config启动编辑配置文件,然后配置文件参考下方修改节点信息:

Log:
  Level: warning # Log level: none, error, warning, info, debug
  AccessPath: # /etc/XrayR/access.Log
  ErrorPath:  /etc/XrayR/error.log
DnsConfigPath: # /etc/XrayR/dns.json # Path to dns config, check https://xtls.github.io/config/dns.html for help
RouteConfigPath: /etc/XrayR/route.json # Path to route config, check https://xtls.github.io/config/routing.html for help
InboundConfigPath: # /etc/XrayR/custom_inbound.json # Path to custom inbound config, check https://xtls.github.io/config/inbound.html for help
OutboundConfigPath: /etc/XrayR/custom_outbound.json # Path to custom outbound config, check https://xtls.github.io/config/outbound.html for help
ConnectionConfig:
  Handshake: 4 # Handshake time limit, Second
  ConnIdle: 30 # Connection idle time limit, Second
  UplinkOnly: 2 # Time limit when the connection downstream is closed, Second
  DownlinkOnly: 4 # Time limit when the connection is closed after the uplink is closed, Second
  BufferSize: 64 # The internal cache size of each connection, kB
Nodes:
  - PanelType: "NewV2board" # Panel type: SSpanel, NewV2board, PMpanel, Proxypanel, V2RaySocks, GoV2Panel
    ApiConfig:
      ApiHost: "https://v2dance.xyz"
      ApiKey: "v2dance_api_key"
      NodeID: 1
      NodeType: V2ray # Node type: V2ray, Shadowsocks, Trojan, Shadowsocks-Plugin
      Timeout: 30 # Timeout for the api request
      EnableVless: true # Enable Vless for V2ray Type
      SpeedLimit: 0 # Mbps, Local settings will replace remote settings, 0 means disable
      DeviceLimit: 0 # Local settings will replace remote settings, 0 means disable
      RuleListPath: # /etc/XrayR/rulelist Path to local rulelist file
    ControllerConfig:
      ListenIP: 0.0.0.0 # IP address you want to listen
      SendIP: 0.0.0.0 # IP address you want to send pacakage
      UpdatePeriodic: 60 # Time to update the nodeinfo, how many sec.
      DeviceOnlineMinTraffic: 100 # V2board面板设备数限制统计阈值,大于此流量时上报设备数在线,单位kB,不填则默认上报
      EnableDNS: false # Use custom DNS config, Please ensure that you set the dns.json well
      DNSType: AsIs # AsIs, UseIP, UseIPv4, UseIPv6, DNS strategy
      EnableProxyProtocol: false # Only works for WebSocket and TCP
      AutoSpeedLimitConfig:
        Limit: 0 # Warned speed. Set to 0 to disable AutoSpeedLimit (mbps)
        WarnTimes: 0 # After (WarnTimes) consecutive warnings, the user will be limited. Set to 0 to punish overspeed user immediately.
        LimitSpeed: 0 # The speedlimit of a limited user (unit: mbps)
        LimitDuration: 0 # How many minutes will the limiting last (unit: minute)
      GlobalDeviceLimitConfig:
        Enable: false # Enable the global device limit of a user
        RedisAddr: 127.0.0.1:6379 # The redis server address
        RedisPassword: YOUR PASSWORD # Redis password
        RedisDB: 0 # Redis DB
        Timeout: 5 # Timeout for redis request
        Expiry: 60 # Expiry time (second)
      EnableFallback: false # Only support for Trojan and Vless
      FallBackConfigs:  # Support multiple fallbacks
        - SNI: # TLS SNI(Server Name Indication), Empty for any
          Alpn: # Alpn, Empty for any
          Path: # HTTP PATH, Empty for any
          Dest: 80 # Required, Destination of fallback, check https://xtls.github.io/config/features/fallback.html for details.
          ProxyProtocolVer: 0 # Send PROXY protocol version, 0 for disable
      EnableREALITY: true # 是否开启 REALITY
      DisableLocalREALITYConfig: false  # 是否忽略本地 REALITY 配置
      REALITYConfigs: # 本地 REALITY 配置
        Show: true # Show REALITY debug
        Dest: uk03.bjdouyin.com:443 # REALITY 目标地址
        ProxyProtocolVer: 0 # Send PROXY protocol version, 0 for disable
        ServerNames: # Required, list of available serverNames for the client, * wildcard is not supported at the moment.
          - uk03.bjdouyin.com
        PrivateKey: # 可不填
        MinClientVer: # Optional, minimum version of Xray client, format is x.y.z.
        MaxClientVer: # Optional, maximum version of Xray client, format is x.y.z.
        MaxTimeDiff: 0 # Optional, maximum allowed time difference, unit is in milliseconds.
        ShortIds: # 可不填
          - "6ba85179e3033fc2"
      CertConfig:
        CertMode: none # Option about how to get certificate: none, file, http, tls, dns. Choose "none" will forcedly disable the tls config.
        CertDomain: "node1.test.com" # Domain to cert
        CertFile: /etc/XrayR/cert/node1.test.com.cert # Provided if the CertMode is file
        KeyFile: /etc/XrayR/cert/node1.test.com.key
        Provider: alidns # DNS cert provider, Get the full support list here: https://go-acme.github.io/lego/dns/
        Email: [email protected]
        DNSEnv: # DNS ENV option used by DNS provider
          ALICLOUD_ACCESS_KEY: aaa
          ALICLOUD_SECRET_KEY: bbb

然后重启XrayR即可。

访问机场首页测试: https://v2dance.xyz/#/home

参考:
